Technical Specifications
KÇ7 | 2KÇ 7+6 | ||||
| Max. Lifting Capacity (at 3 meters) | 107934 kg | 107934 kg | |||
| Max. Hydraulic Boom Extension Reach | 21400 mm | 43090 mm | |||
| Max. Manual Boom Extension Reach | 30200 mm | 53240 mm | |||
| Number of Hydraulic Booms | 7 | 6 | |||
| Number of Manual Booms | 3 | 3 | |||
| Total Lifting Moment | 315 Tonm | ||||
| Operating Pressure | 295 bar | ||||
| Rotation Angle | Infinite / Continuous | ||||
| Max. Outrigger Extension | 9605 mm | ||||
Capacities
| KÇ7 | 2KÇ 7+6 | ||
| mm | kg | mm | kg |
| 3000 | 107934 | 26290 | 4400 |
| 4670 | 67700 | 28840 | 3650 |
| 5500 | 57000 | 31490 | 3060 |
| 7500 | 41000 | 34240 | 2550 |
| 9600 | 30700 | 37090 | 2100 |
| 11800 | 23850 | 40040 | 1660 |
| 14050 | 19000 | 43090 | 1270 |
| 16400 | 15300 | 46360 | 940 |
| 18850 | 12350 | 49740 | 650 |
| 21400 | 9950 | 53240 | 400 |
| 24220 | 7950 | ||
| 27150 | 6300 | ||
| 30200 | 5000 | ||
