Technical Specifications
KÇ7 | 2KÇ 7+6 | ||||
| Max. Lifting Capacity (at 3 meters) | 70674 kg | 70674 kg | |||
| Max. Hydraulic Boom Extension Reach | 21225 mm | 42860 mm | |||
| Max. Manual Boom Extension Reach | 30010 mm | 52960 mm | |||
| Number of Hydraulic Booms | 7 | 6 | |||
| Number of Hydraulic Booms | 3 | 3 | |||
| Total Lifting Moment | 225 Tonm | ||||
| Operating Pressure | 295 bar | ||||
| Rotation Angle | Infinite / Continuous | ||||
| Max. Outrigger Extension | 8350 mm | ||||
Capacities
| KÇ7 | 2KÇ 7+6 | ||
| mm | kg | mm | kg |
| 3000 | 70674 | 26060 | 3350 |
| 5230 | 40540 | 28610 | 2670 |
| 7215 | 28510 | 31260 | 2100 |
| 9300 | 21240 | 34010 | 1620 |
| 11485 | 16460 | 36860 | 1210 |
| 13770 | 13110 | 39810 | 860 |
| 16155 | 10640 | 42860 | 620 |
| 18640 | 8700 | 46120 | 430 |
| 21225 | 7100 | 49490 | 300 |
| 24040 | 5790 | 52960 | 190 |
| 26980 | 4730 | ||
| 30010 | 3370 | ||
